MI 3000 EasiPLUS Maintenance
57
A Fuse base tables
Fuse type B Fuse type C
Disconnection time [s] Disconnection time [s]
0.4 5 0.4 5
Rated
current
(A)
Max. loop impedance ()
Rated
current
(A)
Max. loop impedance ()
3 12,264 12,264
6 6,136 6,136 6 3,064 3,064
10 3,68 3,68 10 1,84 1,84
16 2,296 2,296 16 1,152 1,152
20 1,84 1,84 20 0,92 0,92
25 1,472 1,472 25 0,736 0,736
32 1,152 1,152 32 0,576 0,576
40 0,92 0,92 40 0,456 0,456
50 0,736 0,736 50 0,368 0,368
63 0,584 0,584 63 0,288 0,288
80 0,456 0,456 80 0,232 0,232
100 0,368 0,368 100 0,184 0,184
125 0,296 0,296 125 0,144 0,144
Fuse type D Fuse type BS 88-3 (system C)
Disconnection time [s] Disconnection time [s]
0.4 5 0.4 5
Rated
current
(A)
Max. loop impedance ()
Rated
current
(A)
Max. loop impedance ()
6 1,536 1,536 5 8,36 12,264
10 0,92 0,92 16 1,936 3,288
16 0,576 0,576 20 1,632 2,704
20 0,456 0,456 32 0,768 1,312
25 0,368 0,368 45 0,832
32 0,288 0,288 63 0,576
40 0,232 0,232 80 0,424
50 0,184 0,184 100 0,32
63 0,144 0,144
80 0,112 0,112
100 0,088 0,088
125 0,072 0,072
Fuse type BS 88-2 (systems E and G) Fuse type BS 1362
Disconnection time [s] Disconnection time [s]
0.4 5 0.4 5
Rated
current
(A)
Max. loop impedance ()
Rated
current
(A)
Max. loop impedance ()
6 6,568 10,24 3 13,12 18,56
10 3,912 5,752 13 1,936 3,064
16 2,048 3,344
20 1,416 2,36
Fuse type BS 3036
25 1,08 1,84 Disconnection time [s]
32 0,832 1,472 0.4 5
40 1,08
Rated
current
(A)
Max. loop impedance ()
50 0,832 5 7,664 14,16
63 0,656 15 2,04 4,28
80 0,456 20 1,416 3,064
100 0,368 30 0,872 2,112
125 0,272 45 1,272
160 0,224 60 0,896
200 0,152 100 0,424
All impedances are scaled with factor 0.8.
