MI 3000 EasiPLUS Instrument operation
21
Press the HELP key again to see further Help screens (if available) or to return to the
function menu.
Figure 4.3: Example of help menu
4.5 Setup menu
In the Setup menu, the following actions can be taken:
 Supply system selection,
 Impedance scaling factor adjustment
 Language selection,
 Support for remote commanders
To enter the Setup menu press the BACKLIGHT key and rotate function selector switch
in any direction at the same time.
Rotate function selector switch again to leave Setup menu or setup sub-menus.
Figure 4.4: Setup menu
4.5.1 Supply system setup
The instrument enables tests and measurements in the following supply systems:
 TN (TT) system,
 IT system,
 Reduced low voltage system (255 V),
 Reduced low voltage system (363 V).
Select SYSTEMS in the Setup menu by using  and  keys and press the TEST key
to enter the Supply system setup menu.
Figure 4.5: Supply systems selecting menu
By using  and  keys select supply system and press the TEST key to accept the
setting.
