METREL EasiPLUS MI 3000 User Manual

MI 3000 EasiPLUS Instrument description
15
Legend:
1........Fuse F1.
2........Fuse F2.
3........Fuse F3.
4........Serial number label.
5........Battery cells (size AA).
6........Battery holder.
3.3 Bottom view
Continuity 7mA
R: 0.0 1999
Test current: max. 7mA
Open-circuit voltage: 5.4V 7.2V
 

DC
DC DC
Insulation resistance (EN 61557-2)
R: 0.000M 199.9M , U =100V , 250V
R: 0.000M 999M , U = 500V , 1kV
U: 0V 1200V,
Nominal voltages: 100V , 250V , 500V , 1kV
Measuring current: min. 1mA at R =U 1k /V
Short-circuit current: <3mA
 
 


NDCDC
NDCDC
DC DC DC DC
NN
DC
R: 0.00 1999
Test current: min. ±200mA
Open-circuit voltage: 5.4V 9.0V
Low 
 

DC DC
Tripping time
non-delayed (time-delayed) RCDs
t : 0ms 300ms (500ms)
t : 0ms 150ms (200ms)
t : 0ms 40ms (150ms)
U : 0.00V 100.0V







C
Tripping current
I : 0.2 I 1.1 I
t : 0ms 300ms
U : 0.00V 100.0V
 

 


NN
C
Contact voltage
U : 0.00V 100.0V
R : 0.00 10.00k (R =U / I )
C
SSC N

 

Fault loop resistance (without tripping RCD)
R : 0.00 10k
U : 0.00V 100.0V, (U =R I )
S
CCS N
 
 

Line resistance
R : 0.00 1999
I : 0.06A 24.4kA
Nominal voltage: 100V 440V / 45Hz 65Hz
L-N(L)
PSC
AC AC
 


Fault loop resistance (EN 61557-3)
R : 0.00 1999
I : 0.06A 24.4kA
Nominal voltage: 100V 440V / 45Hz 65Hz
L-PE
PFC
AC AC
 


Voltage, frequency
U: 0V 440V
f: 45Hz 65Hz


Phase rotation (EN 61557-7)
Nominal voltage: 100V 440V / 45Hz 65Hz
Results: 1.2.3. or 2.1.3
AC AC

I : 10mA, 30mA, 100mA, 300mA, 500mA, 1A
Multiplier: / 1, 2, 5
Nominal voltage: 100V 264V / 45Hz 65Hz
 N
2
AC AC

 
1
RCD (EN 61557-6)
Continuity (EN 61557-4)
3
1
2
Figure 3.5: Bottom view
Legend:
1........Information label.
2........Neck strap openings.
3........Handling side covers.
