Functional Description
46 50,000-count Benchtop Multimeter
Functional Description (continued)
MATH " MATH " mode enables users to measure a given physical magnitude such as:
• Volts (0 - 10 V process, for example)
• Amps (4 - 20 mA current loop, for example)
• Frequency (measuring rate or rotation speed, for example)
• Ohms (resistive position sensor, for example)
convert it and assign the adequate unit in order to obtain a direct reading of
the original magnitude on the instrument.
"MATH" mode
management
Func V, A, ΩΩ, Hz
rAnGE
PArAM A
PArAM b
, µ, m, K, M, G
Unit A to Z, ΩΩ and Hz
Keep the " MATH " key pressed down to access and exit this mode.
Six-phase programming is performed by successively pressing " MATH ",
then setting and validating the following via code wheel:
• Definition of measured magnitude
• Choice of measurement range
• Definition of coefficient A of function y = Ax + b
• Definition of coefficient B of function y = Ax + b (SI unit)
• Choice of physical unit prefix to be displayed
• Choice of physical unit to be displayed
MENU The " MENU " mode enables users to define their own preferences for
certain instrument operation options and update internal clock date and
time.
"MENU" mode
management
bEEP On, bEEP OFF
SLEEP On, SLEEP OFF
Cont
bAud
SEtUP bASIC,
SEtUP uSER
rEJEC
Pt 100, Pt 1000
FILt On, FILt OFF
IMP 10MΩΩ, IMP 1GΩΩ
Programming is performed in successive phases by pressing " MENU ",
then setting and validating the following via code wheel:
• Validation or not of beep when pressing a key or during a warning while
unit is in operation.
• Validation or not of automatic stop after 30 minutes operation if, during this
period, no action was performed on the front.
• Step setting of LCD contrast (0, 33, 67, 100 %)
• Parameterisation of transmission speed: 9600 / 19200 / 38400 / 57600.
Other transmission characteristics are fixed (8 data bits, 1stop bit, no
parity).
• When turning instrument on," bASIC " will allow you to find the
instrument’s basic configuration, while " uSER " will show the last "
advanced " configuration set up by the user for each instrument mode;
this particularly allows you to adapt to " multi-user " instrument operation
(choose "bASIC" option).
• 50 Hz or 60 Hz: choice of network frequency used for optimal rejection.
• Parameterisation of plate sensor type, 100 Ω ou 1000 Ω a 0°C, used to
measure temperature.
• Select "FILt On" in order to measure the average value of alternating
signals via VDC mode.
• Allows you to choose 500 mV range input impedance.
