50,000-count Benchtop Multimeter 51
Technical specifications
Measuring
frequency (Hz)
Main frequency
On this position, users can measure voltage frequency.
(∗) 500 mV available for 10 MΩ inpur resistance
Measurement is performed by capacitive coupling.
Voltage range can be selected in manual mode by keeping the "Hz" key
pressed down.
Input resistance: 10 MΩ (11 MΩ on 5 V range)
Permanent admissible maximum voltage: 600 V
rms
Varistance protection on voltage input.
Voltage frequency
or parallel current
Users can measure voltage frequency and magnitude.
(∗) 1 kHz max. for 500 µA and 500 mV
(∗∗) 500 mV available for 10 MΩ / 1 GΩ input resistances
Measurement is performed by capacitive coupling.
Input resistance: 10 MΩ (11 MΩ on 5 V range).
Permanent admissible maximum voltage: 600 Vrms
Range Precision Resolution Admissible overload
1 Hz to 5 Hz 0.03% + 2D 0.0001 Hz
50 Hz 0.03% + 2D 0.001 Hz
500 Hz 0.03% + 2D 0.01 Hz
5 kHz 0.03% + 2D 0.1 Hz
50 kHz 0.03% + 2D 1 Hz
500 kHz 0.05% + 2D 10 Hz
1 MHz 0.05% + 2D 100 Hz
Range Precision Resolution Admissible overload
1 to 5 Hz 0.03% + 5D 0.001 Hz
50 Hz 0.03% + 5D 0.01 Hz
500 Hz 0.03% + 5D 0.1 Hz
5 kHz 0.05% + 5D 1 Hz
50 kHz 0.05% + 5D 10 Hz
100 kHz 0.05% + 5D 100 Hz
Sensitivity (rectangular signals)
Range
5 V (∗) to 500 V
600 V
1 Hz to 5 kHz 2 % of rate 100 V
5 kHz to 50 kHz 5 % of rate 250 V
50 kHz to 500 kHz 10 % of rate
500 kHz to 1 MHz 20 % of rate
Sensitivity (rectangular signals) Vrms
Range
(∗∗) 5 V (∗) to 500 V
500 µA to 10 A
1 Hz to 5 kHz 10% of rate
15 % of rate (∗)
5 kHz to 50 kHz 10% of rate 15 % of max. rate
10 kHz
50 kHz to 100 kHz 20% of rate
(cont.)
1000 VDC
or
700 VAC
(1 min max.)
1000 V
DC
or
700 VAC
(1 min max.)
