kajaaniMCA
i
– Installation, Operating & Service - 4.1 - W4610201 V2.5 EN
4. Start-up
4.A. Mechanics Check
1. Make sure that the delivery is consistent with the
order.
2. Check the equipment for damage that may have
occurred during shipment or installation work.
3. Make sure that the connectors of the Display Unit
and all cables are in their proper places.
4.B. Installation
Install the sensor to process following the installation
instructions.
4.C. Checking the Cable Connections
1. Make sure that the mains voltage cables are correct-
ly made and connected.
2. Make sure that the current output cables are correct-
ly connected.
3. Make sure that the alarm output cable is correctly
connected.
4. Make sure that the analog and binary output cables
(if any) are correctly connected.
4. Make sure that the cable between sensor and Display
Unit is correctly connected.
4.D. Checking Electric Operation
1. Plug the Communicator-i to the quick connector on
the bottom of the Display Unit.
2. Switch power on to the system.
3. Make sure that the display of the Communicator-i
shows an image.
NOTE: Allow the sensor to warm up for about 3 hours
before commencing the start-up!
4.E. Configuration
1. If the Communicator-i shows the Main Menu, do
Reset-Abort. If the Communicator-i prompts you to
select the sensor type, you may continue without
Reset-Abort.
2. Complete the initial configuration as instructed in
section 6.A.
3. Calibrate the sensor as instructed in section 7.A.
4. Scale the necessary current outputs as instructed in
section 6.B.
The sensor is now ready to start measurement.
