Fig. 6.10. Device info (settings) display.
SETTINGS SW V2.5
Date: 18-10-00
Time: 10:20
Installation info: “MCAI DESCRIPTOR”
Tag number: “MCAI-000”
Use password: No
Temperature unit: CELSIUS
Language: ENGLISH
Edit Error Simul. Reset-
limits cable Abort
6.C. Editing Device Information
S
ELFDIAGNOSTICS => SETTINGS (Fig. 6.10).
Device information can be edited in the “Settings”
display. Press [F1&F2] E
DIT to start editing. Type the
required values with the keypad; in the last three fields
changes can be made by pressing [F5&F6] R
OLL. Press
[F3&F4] S
AVE to save the changes.
Settings in this display:
• Installation info: you can type here a text describ-
ing the installation point; this text will be shown in
the top left corner of the Main Menu.
• Tag number: the sensor’s identification number;
will be shown in the top left corner of the Main
Menu.
• Use password: select YES or NO.
• Temperature unit: select Celsius or Fahrenheit
degrees (°C/°F).
• Language: select display language.
6.D. Reset-Abort
S
ELFDIAGNOSTICS => SETTINGS (Fig. 6.10).
Press [F7&F8] R
ESET-ABORT to reset the settings.
The software will ask for confirmation before proceed-
ing. If YES is selected, the software will be reset and has
to be configured again as instructed in section 6.A.
The Reset-Abort command can also be given with
the corresponding buttons located on the Field Connec-
tion Board of sensor electronics.
NOTE: Reset-Abort will erase all stored configurations
from the memory and initialize the device with system
defaults!
