Metso Mapag BAR Series User Manual

2 BAR 70 en 7
Table 1 Stud bolt BARDA06 Table 2 Stud bolt BARFA06
Table 3 Stud bolt BARMA06 Table 4 Stud bolt BARNA03
Table 5 Stud bolt BARDA03 Table 6 Stud bolt BARFA03
Table 7 Stud bolt BARMA03 Table 8 Stud bolt BARNA03
Table 9 Stud bolt ARDA04 Table 10 Stud bolt BARFA04
Table 11 Stud bolt BARMA04 Table 12 Stud bolt BARNA04
NPS Thread K
LL1
Length Number Length Number
3 3/4"-10UNC 210 4 80 8
4 3/4"-10UNC 210 4 85 8
6 3/4"-10UNC 240 8 90 8
8 7/8"-9UNC 270 8 105 8
10 1"-8UN 310 12 115 8
12 1 1/8"-8UN 340 12 125 8
16 1 1/4"-8UN 420 16 145 8
20 1 1/4"-8UN 450 20 150 8
NPS Thread K
LL1
Length Number Length Number
3 3/4"-10UNC 230 4 85 8
4 7/8"-9UNC 250 4 100 8
6 1"-8UN 290 8 110 8
8 1 1/8"-8UN 320 8 125 8
10 1 1/4"-8UN 365 12 135 8
12 1 1/4"-8UN 390 16 140 8
16 1 1/2"-8UN 485 16 165 8
20 1 5/8"-8UN 515 20 190 8
DN Thread K
LL1
Length Number Length Number
80 M16 200 4 70 8
100 M20 210 4 85 8
150 M24 245 8 100 8
200 M27 275 8 110 8
250 M30 310 12 120 8
300 M30 340 12 130 8
400 M36 425 16 145 8
500 M39 450 16 160 8
DN Thread K
LL1
Length Number Length Number
80 M20 230 4 85 8
100 M24 240 4 100 8
150 M30 280 8 115 8
200 M33 310 8 130 8
250 M33 340 12 135 8
300 M33 375 16 140 8
400 M39 470 16 160 8
500 M45 n.a 16 n.a. 8
NPS Thread K
L
Length Number
3 3/4"-10UNC 100 8
4 3/4"-10UNC 110 8
6 3/4"-10UNC 120 12
8 7/8"-9UNC 135 12
10 1"-8UN 150 16
12 1 1/8"-8UN 160 16
16 1 1/4"-8UN 180 20
20 1 1/4"-8UN 200 24
NPS Thread K
L
Length Number
3 3/4"-10UNC 115 8
4 7/8"-9UNC 120 8
6 1"-8UN 130 12
8 1 1/8"-8UN 150 12
10 1 1/4"-8UN 170 16
12 1 1/4"-8UN 180 20
16 1 1/2"-8UN 200 20
20 1 5/8"-8UN 210 24
DN Thread K
L
Length Number
80 M16 100 8
100 M20 110 8
150 M24 130 12
200 M27 145 12
250 M30 160 16
300 M30 170 16
400 M36 195 20
500 M39 220 24
DN Thread K
L
Length Number
80 M20 110 8
100 M24 125 8
150 M30 150 8
200 M33 170 12
250 M33 180 12
300 M33 190 16
400 M39 225 16
500 M45 not applicable 20
NPS Thread K
L1
Length Number
3 3/4"-10UNC 80 8
4 3/4"-10UNC 85 8
6 3/4"-10UNC 90 8
8 7/8"-9UNC 105 8
10 1"-8UN 115 8
12 1 1/8"-8UN 125 8
16 1 1/4"-8UN 145 8
20 1 1/4"-8UN 150 8
NPS Thread K
L1
Length Number
3 3/4"-10UNC 85 8
4 7/8"-9UNC 100 8
6 1"-8UN 110 8
8 1 1/8"-8UN 125 8
10 1 1/4"-8UN 135 8
12 1 1/4"-8UN 140 8
16 1 1/2"-8UN 165 8
20 1 5/8"-8UN 190 8
DN Thread K
L1
Length Number
80 M16 70 8
100 M20 85 8
150 M24 100 8
200 M27 110 12
250 M30 120 12
300 M30 130 16
400 M36 145 16
500 M39 160 20
DN Thread K
L1
Length Number
80 M20 85 8
100 M24 100 8
150 M30 115 8
200 M33 130 12
250 M33 135 12
300 M33 140 16
400 M39 160 16
500 M45 not applicable 20
