Metso ND9200F User Manual

7 ND92F 70 en 41
15 TYPE CODING
INTELLIGENT VALVE CONTROLLER ND9200F /
LIMIT SWITCH (ND9200F/I00, ND9200F/K00 or ND9200F/B06)
1. 2. 3. 4. 5. 6. 7. 8. 9.
ND9203 FE1M /B06
1. PRODUCT GROUP
ND Intelligent Valve Controller
2. SERIES CODE
9
Series 9000 valve controller with universal shaft and attachment
face according to standard VDI/VDE 3845,
EC/EJ actuators and old Neles standard.
Relevant shaft adapter included in mounting kits. When valve
controllers are separate deliveries, shaft adapter kit is supplied.
3. ENCLOSURE
20 Flameproof (Ex d) IP66 / NEMA 4X enclosure
4. SPOOL VALVE
PNEUMATIC CONNECTIONS
(S, C1, C2)
2
Low capacity. Stroke volume
of actuator < 1 dm
3
1/4 NPT
3
Medium capacity. Stroke volume
of actuator 1...3 dm
3
1/4 NPT
6
High capacity. Stroke volume
of actuator > 3 dm
3
1/4 NPT
5. COMMUNICATION / INPUT SIGNAL RANGE
F FOUNDATION Fieldbus, physical layer according to IEC 61158-2.
6. APPROVALS OF STANDARD ENCLOSURE VALVE CONTROLLER
E1
Flameproof enclosure, M20 x 1.5 conduit entry.
ATEX certifications:
- II 2 G Ex d IIC T4...T6 (EN 60079-0:2006, EN 60079-1:2004)
- II 2 D Ex tD A21 IP66 T 100 °C (EN 61241-0:2006,
EN 61241-1:2004)
ND92_FE1: Ui ≤32 V
Temperature range: T4; -40° to +85 °C / -40° to +185 °F
T5; < +75 °C / < +167 °F, T6; < +60 °C / < +140 °F
E2
Flameproof enclosure, 1/2 NPT conduit entry.
Temperature range: -40° to +80 °C / -40° to +176 °F.
FM / CSA certifications (pending):
- Class I, II and III, Division 1 and 2, Groups A, B, C, D, E, F
(Group A FM only).
ND92_FE2: Ui ≤32 V
Temperature range: T4; -40° to +85 °C / -40° to +185 °F
T5; < +75 °C / < +167 °F, T6; < +60 °C / < +140 °F
7. OPTIONS OF VALVE CONTROLLER
M
Special corrosion resistant finish. External aluminium
surfaces protected by hard anodizing with PTFE. Coating
thickness 20 µm. Not painted. Not available with 7. sign G.
G
Exhaust adapter. 1 x 1/2 NPT thread.
Not available with 7. sign M.
Y Special construction, to be specified.
8. LIMIT SWITCH TYPE
Inductive proximity switches, 2 pcs.
IP66 / NEMA 4X enclosure. M20 x 1.5 conduit entry (2 pcs).
I02
P+F; NJ2-12GK-SN, 2-wire type, DC; > 3 mA; < 1 mA.
Intrinsically safe according to ATEX II 2 G EEx ia IIC T6.
Temperature range -40° to +51 °C / -40° to +124 °F.
I09
P+F; NCB2-12GM35-N0, 2-wire type, DC; > 3 mA; < 1 mA.
Intrinsically safe according to ATEX II 2 G EEx ia IIC T6.
Temperature range -25° to +100 °C / -13° to +212 °F.
I56
ifm IFC2002-ARKG/UP, 2-wire type, DC; 150 mA, 10 – 36 V DC,
leakage current < 0.6 mA.
Temperature range -20° to +80 °C / -4° to +176 °F.
Mechanical micro switches, 2 pcs.
IP66 / NEMA 4X enclosure. M20 x 1.5 conduit entry (2 pcs).
K05
OMRON D2VW-5; 3 A - 250 V AC, 0.4 A - 125 V DC, 5 A - 30 V DC.
Temperature range -40° to +80 °C / -40° to +176 °F.
K06
OMRON D2VW-01; gold plated contacts, 100 mA - 30 V DC / 125 V AC.
Temperature range -40° to +80 °C / -40° to +176 °F.
Bus powered mechanical micro switches, 2 pcs.
IP 66 / NEMA 4X enclosure. M20 x 1.5 conduit entry (2 pcs).
B06
OMRON D2VW-01; gold plated contacts, Bus powered, no
external power and cabling needed.
Temperature range -40° to +80 °C / -40° to +176 °F.
9. OPTIONS OF LIMIT SWITCH
Y Special construction, to be specified.
