Sonicator Plus 930 Instruction Manual— Rev.J_09/13/17
13
Section 3—Installation
3.1 Installation Instructions
1. Connect the line cord to the back of the Sonicator Plus 930. (See Figure 3.1)
2. Plug the line cord (ME 7293) into a grounded wall outlet that is rated between 90–240
VAC, 50–60 Hz. Your power supply must match the voltage requirements listed on the
serial number label of your device. Do not connect the Sonicator Plus 930 to a power
supply rated differently than that described above.
3. The line cord comes equipped with a standard 3–prong plug. This plug provides
grounding for the Sonicator Plus 930. Do not defeat its purpose by using 3–to–2 prong
adapters or any other means of attaching to a wall outlet.
4. Push the hooded, water-proof applicator cable connector (ME 7392) into the round
BNC receptacle located on the front of the Sonicator Plus 930. (See Figure 3.2) Connect
the applicator model 7513 to universal applicator cable using the BNC connector. (See
Figure 3.3). Secure both connectors by lining up the pegs, pushing in all the way and
rotating ¼ turn clockwise. To maintain waterproof characteristics of the BNC
connectors make sure that all connections are dry before attempting to connect them.
5. Place the applicator into the applicator cradle.
6. Plug the electrode cables (ME 2260) into the electrode cable connections as seen in
Figure 3.2. For combination therapy procedures, plug the single line electrode cable
(ME 2261) into the electrode connection for Channel 1.
7. The Sonicator Plus 930 may be susceptible to interference originating from shortwave
diathermy units operating in close proximity to it. Avoid operating the Sonicator Plus
930 adjacent to and simultaneously with operating shortwave devices.
8. Do not use sharp objects to operate the membrane panel switches. If the tough outer
layer of the membrane is broken, moisture may leak into the switches resulting in
switch failure.
9. Once you have verified proper functioning of your Sonicator 740, using the instructions
in Section 4, please register the warranty for your Sonicator Plus 930 on line at
http://www.mettlerelectronics.com/product-registration/.
