Mettler Electronics Corp.— Rev.J_09/13/17
54
9.4 Waveform Specifications:
Interferential Mode
Figure 9.7—Interferential
Waveform
Waveform Type: Sinewave
Polarity: None
Volts: 0–65 volts RMS, 1 Kohm load
Current: 0–65 mA RMS, 1 Kohm load
Average current at
maximum intensity
and frequency: 65 mA RMS
Maximum current
density under 2"
diameter electrode. 3.2 mA/cm²
Frequency: Channel 1 = 4000 Hz
Channel 2 = 4000 to 4250
Hz variable frequency sine
wave
Frequency Modulation: 1–15 Hz
80–150 Hz
1–150 Hz
xx–xx Hz,
xx=any value from
1 to 250 Hz
Phase Duration: 125 s
Available Amplitude
Modulation Options: Vector rotation
Available Channels: Channels 1 & 2
