Mettler Electronics Sonicator Plus 930 - Sonicator Plus 930, Back View-Mains Power Switch and Line Cord Connection; Sonicator Plus 930, Front View-Electrode Cable and Ultrasound Applicator

Mettler Electronics Corp.— Rev.J_09/13/17
14
Mains Power Switch
Line Cord Connection
Figure 3.1— Sonicator Plus 930, Back View—
Mains Power Switch and Line Cord Connection
1 2
!
Electrode Cable Connections
Ultrasound Cable Connection
Figure 3.2— Sonicator Plus 930, Front View—
Electrode Cable and Ultrasound Applicator Connections
Figure 3.3—Connecting the Applicator to the Universal Applicator Cable, line up pegs,
push in all the way and rotate ¼ turn clockwise
