Sonicator Plus 930 Instruction Manual— Rev.J_09/13/17

Premodulated Mode

Figure 9.8—Premodulated

Waveform

Waveform Type: Amplitude modulated

sine wave

Polarity: None

Volts: 0–50 volts RMS, 1 Kohm load

Current: 0–50 mA RMS,

1 Kohm load

Average current at

maximum intensity

and frequency: 50 mA RMS

Maximum current

density under 2"

diameter electrode. 2.5 mA/cm²

Frequency: 4,000 Hz

Frequency Modulation: 1–15 Hz

80–150 Hz

1–150 Hz

xx–xx Hx,

xx=any value from

1 to 250 Hz

Phase Duration: 125 s internal sine wave

4–1,000 ms beat envelope

Available Amplitude

Modulation Options: Continuous

Surge

Reciprocation

Available Channels: All
