Operating Instruction X-Type plus
Operating instructions X-Type plus V1-3.docx Page 31 of 45
The following control panels are available:
Indexes/moves the turntable directly to the next print station
on the left.
Indexes/moves the turntable directly to the next print station
on the right.
Moves the turntable into the clean/half index position.
Allows the operator to lock or release the pallets.
Unlocks the turntable and allows free manual turning.
Raises or lowers the screens to off-contact position.
Lock and Unlock the screen pneumatically.
Moves all squeegees to the outer position.
Moves all squeegees to the inner position.
