Microchip Technology MPLAB ICD 5 User Manual

Error Messages
User Guide
© 2023 Microchip Technology Inc. and its subsidiaries
DS-50003529B - 67
If these actions fail to x the problem, see Debugger to Target Communication Error Actions and
Debug Failure Actions.
8.1.3 Miscellaneous Errors
ICD 5 is busy. Please wait for the current operation to nish.
1. Wait. Give the debugger time to nish any application tasks. Then try to deselect the debugger
again.
2. Select (Finish Debugger Session) to stop any running applications. Then try to deselect the
debugger again.
3. Unplug the debugger from the computer. Then try to deselect the debugger again.
4. Shut down MPLAB X IDE.
8.1.4 List of Error Messages
Table 8-1. Alphabezed List Of Error Messages
AP_VER=Algorithm Plugin Version.
AREAS_TO_PROGRAM=The following memory area(s) will be programmed:
AREAS_TO_READ=The following memory area(s) will be read:
AREAS_TO_VERIFY=The following memory area(s) will be veried:
BLANK_CHECK_COMPLETE=Blank check complete, device is blank.
BLANK_CHECKING=Blank Checking...
BOOT_CONFIG_MEMORY=boot cong memory.
BOOT_VER=Boot Version.
BOOTFLASH=boot ash.
BP_CANT_B_DELETED_WHEN_RUNNING=software breakpoints cannot be removed while the target is running. The selected
breakpoint will be removed the next time the target halts.
CANT_CREATE_CONTROLLER=Unable to nd the tool controller class.
CANT_FIND_FILE=Unable to locate le %s.
CANT_OP_BELOW_LVPTHRESH=The voltage level selected %f, is below the minimum erase voltage of %f. The operation
cannot continue at this voltage level.
CANT_PRESERVE_PGM_MEM=Unable to preserve program memory: Invalid range Start = %08x, End = %08x.
CANT_READ_REGISTERS=Unable to read target register(s).
CANT_READ_SERIALNUM=Unable to read the device serial number.
CANT_REMOVE_SWPS_BUSY=The ICD 5 is currently busy and cannot remove software breakpoints at this time.
CHECK_4_HIGH_VOLTAGE_VPP=CAUTION: Check that the device selected in MPLAB X IDE (%s) is the same one that is
physically attached to the debug tool. Selecting a 5V device when a 3.3V device is connected can result in damage to the
device when the debugger checks the device ID. Do you wish to continue?
CHECK_PGM_SPEED=You have set the program speed to %s. The circuit on your board may require you to slow the speed
down. Please change the setting in the tool properties to low and try the operation again.
COMM_PROTOCOL_ERROR=A communication error with the debug tool has occurred. The tool will be reset and should
re-enumerate shortly.
COMMAND_TIME_OUT=ICD 5 has timeout out waiting for a response to command %02x.
CONFIGURATION=conguration.
CONFIGURATION_MEMORY=conguration memory.
CONNECTION_FAILED=Connection Failed.
CORRUPTED_STREAMING_DATA=Invalid streaming data has been detected. Run time watch or trace data may no longer be
valid. It is recommended that you restart your debug session.
CPM_TO_TARGET_FAILED=An exception occurred during ControlPointMediator.ToTarget().
DATA_FLASH_MEMORY=Data Flash memory.
