Figure 9-1. Project Properes - ICD 5 Opons
9.2.1 Memories to Program
Select the memories to be programmed into the target.
If “Erase All Before Program” is selected under Program Options, then all device memory will be
erased before programming. To select only certain memories to program after erase, check the
specic memory type. To preserve the value of memory of dierent types, check to preserve that
memory type and check the specic memory type; checking “Preserve Memory” writes the current
contents to a buer before erase, and checking “Memory” writes the contents back into that memory
after erase, where Memory is the type of memory, such as EEPROM.
Table 9-1. Memories to Program Opon Category
Auto select memories and
ranges
Allow ICD 5 to Select Memories – The debugger uses your selected device and default
settings to determine what to program.
Manually select memories and ranges – You select the type and range of memory to
program (see below).
Conguration Memory
(always programmed in
debug mode)
Check to program conguration memory in release mode. For dual partition devices, another
selection for partition 2 will be available.
Memory Check to program Memory. Types of memory include: Instruction RAM, Flash Data, Data
Flash, EEPROM, ID, Boot Flash, Auxiliary.
Memory Range(s) (hex)* The starting and ending hex address range in Memory. Types of memory include: Instruction
RAM.
Program Memory Check to program the target program memory range specied below.
Program Memory Range(s)
(hex)*
The starting and ending hex address range in program memory for programming, reading, or
verication.
Note: The address range does not apply to the Erase function. The Erase function will erase
all data on the device.
