4.0 Configuration
Source IPs
Match incoming traffic from the specified source IP range. Boxes accept
single IP Addresses without network masks, example: 192.168.1.0 to
192.168.1.255 represents all IP Addresses in the 192.168.1.0/24 network.
(Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0
Destination
Select the zone which is the intended destination of the data traffic. WAN
applies to the wireless connection to the cellular carrier and the LAN refers
to local connections on the IPn4G (Ethernet/WiFi)
Values (selection)
LAN
WAN
(Additional LAN Interfaces)
None
Destination IPs
Match incoming traffic from the specified destination IP range. Boxes
accept single IP Addresses without network masks, example: 192.168.1.0
to 192.168.1.255 represents all IP Addresses in the 192.168.1.0/24
network. (Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0
Destination Port
Match incoming traffic directed at the given destination port or port range.
(To specify a port range use a From:To (100:200) format)
Values (port)
0
Protocol
The protocol field defines the transport protocol type controlled by the rule.
Values
TCP
UDP
Both
ICMP
