Microhard Systems IPN4G - Client to Gateway (L2 TP Client)

© Microhard Systems Inc. 118
4.0 Configuration
Image 4-9-3: VPN > Client to Gateway
4.9.3 VPN > Client To Gateway (L2TP Client)
The IPn4G can operate as a L2TP Client, allowing a VPN connection to be made with a L2TP Server.
Tunnel Name
Enter a name for the VPN Tunnel. Up to 16 different tunnels can be
created, each requiring a unique name.
Values (chars)
tunnel1
Enable
Used to enable (checked) is disable (unchecked) the VPN tunnel.
Values (checkbox)
Enable (Checked)
