Device Cradle
CE-500 Device Enhanced Cradle Components
GDUTUG500/01
CE-500 MDT Hardware Guide
74 / 97
Figure 40 – CE-500 Device Enhanced Cradle, Rear Panel
For more information on Enhanced Cradle rear panel components, see:
 +Vin Connector, on page 76
 LAN connector, on page 78
 COM1 Connector, on page 76
COM1 Connector
+Vin Connector
USB Connector
Video-in1 connector
(Full)
Video-in2 connector
LAN connector
COM2 Connector
Spare Connector
Right speaker connector
Left speaker connector
Mounting Arm screw inserts
Audio-in connector
Cables holding handle
Release knob
Audio-out connector
CANBus connector
M_Control1 Connector
Microphone connector
