HAWK MV-4000 Smart Camera Guide vi
Contents
PREFACE Welcome viii
Purpose of This Manual viii
Manual Conventions viii
CHAPTER 1 Introduction 1-1
Product Summary 1-2
Features and Benefits 1-3
Applications 1-4
Package Contents 1-4
HAWK MV-4000 Smart Camera Models 1-5
HAWK MV-4000 Part Number Structure 1-6
CHAPTER 2 System Components 2-1
Hardware Components and Accessories 2-2
HAWK MV-4000 Dimensions 2-6
Label Information 2-10
Mounting, Connecting, and Wiring 2-11
Connecting to the I/O Interface 2-17
Input/Output Wiring Using Flying Lead Cable 61-9000151-01 2-37
Ground and Shield Considerations 2-38
Electrical and I/O Specifications 2-40
Environmental Specifications 2-41
Status Indicators 2-42
Adding a HAWK MV-4000 to a Network 2-43
Setting Up a Job in AutoVISION 2-44
Trigger Debounce 2-49
Setting Up Partial Scan 2-51
CHAPTER 3 Lighting 3-1
Illumination 3-2
External Illumination Control and Wiring 3-3
