Microsemi IGLOO2 - Table 5 Programming Bitstream Size (All Variations T;S;TS)

Programming Overview
UG0451 User Guide Revision 7.0 10
Note:
Table 5 • Programming Bitstream Size (All Variations T/S/TS)
Device File Type
Full Fabric
(in KB)
Full eNVM
(in KB)
Full Fabric + Full
eNVM (in KB)
Full Fabric + Full eNVM +
Custom Security (in
KB)
1
1. File size with custom security is larger because of the encryption added to the file.
M2S005/M2GL005 STAPL 522 270 731 1409
SPI
2
2. SPI file size with and without custom security option is the same, because the security component in it is small.
296 135 429 429
DAT 297 135 431 860
M2S010/M2GL010 STAPL 933 482 1354 2655
SPI 556 269 823 823
DAT 557 269 825 1648
M2S025/M2GL025 STAPL 1945 482 2367 4679
SPI 1195 269 1463 1463
DAT 1197 269 1464 2926
M2S050/M2GL050 STAPL 3792 482 4213 8373
SPI 2363 269 2630 2630
DAT 2364 269 2632 5261
M2S060/M2GL060 STAPL 3799 480 4211 8360
SPI 2363 263 2624 2624
DAT 2364 263 2625 5248
M2S090/M2GL090 STAPL 5690 900 6526 12996
SPI 3561 532 4092 4092
DAT 3564 533 4095 8186
M2S150/M2GL150 STAPL 9539 900 10376 20696
SPI 5996 532 6527 6527
DAT 5997 533 6528 13054
