Programming Recovery
UG0451 User Guide Revision 7.0 39
9.2 SPI Flash Configuration and Image Selection
The image needs to be written to the external SPI flash connected to SPI_0. The SPI directory contains
the addresses of the programming bitstreams stored in the SPI flash. Libero SoC creates the SPI
directory (<file_name>.spidir) as part of the bitstream based on user preference. The following table
describes the SPI directory. For more information, see the Libero SoC User Guide.
9.2.1 MSS/HPMS SPI_0 Port Configuration
The SPI_0 port must be configured while enabling programming recovery and/or auto update in the
Libero SoC software. Set the SPI clock and SPI data transfer mode in the Libero SoC software in the
Configure Programming Recovery window.
Note: SPI mode of a blank device is set to 3 (SPO=SPH=1). To operate the SPI bus in other modes, configure
them in the Libero SoC software. For more information, see the Libero SoC User Guide.
Note: SPS is set to 1.
Table 22 • SPI Directory
Offset Name Description
0 GOLDEN_IMAGE_ADDRESS[3:0] Contains the address where the golden image starts.
4 GOLDEN_IMAGE_DESIGNVER[1:0] Contains the design version of the golden image.
6 UPDATE_IMAGE_ADDRESS[3:0] Contains the address where the update image starts.
10 UPDATE_IMAGE_DESIGNVER[1:0] Contains the design version of the update image.
Table 23 • User Lock Row Strobe Bits for Programming Recovery
Name Description
U_IAPRECOVERY_CLKRATE[7:0] Sets the SPI clock frequency.
U_IAPRECOVERY_CLKMODE 0: Sets SPICLK using 1/(2**(CLKRATE+1))
Where, CLKRATE = 0 to 15
1: Sets SPICLK using 1/(2*(CLKRATE+1)
Where, CLKRATE = 0 to 255
U_IAPRECOVERY_SPO Control SPI signal polarity. See Ta b le 25 , page 40.
U_IAPRECOVERY_SPH Control SPI signal polarity. See Ta bl e 25 , page 40.
U_IAPRECOVERY_DPC[9:0] These set the SPI port I/Os settings.
Table 24 • SPI Signal Polarity Modes
SPO SPH
SPI
Clock in
Idle
Sample
Edge
Shift
Edge
SPI
Select in
Idle SPI Select Between Frames
0 0 Low Rising Falling High Stays active until all the frames set by frame
counter are transmitted.
0 1 Low Falling Rising High
1 0 High Falling Rising High
1 1 High Falling Falling High
