● Changing the Scan Frame settings (width or height) will change the
Output settings (width or height).
● Changing the Output settings (width or height) will change the Scan
Frame settings (width or height).
● Changing the Scaling will change the Output settings (width AND
height).
Scan Frame settings
The Scan Frame settings (width and height) represent the area on the
scan bed that you wish to scan.
To specify your settings, enter the dimensions manually in the width and
height edit boxes; or use the Scan Frame tool to define or resize your scan
frame. Changes made in the Preview window are automatically displayed
in the Scan Frame setting edit boxes.
If you wish, you can also choose from a menu of predefined Scan Frame
settings. To do this, point your mouse to the words "Scan Frame" in the
Settings window, and choose the setting you wish from the drop-down
menu that appears.
Output settings
The Output settings (width and height) represent the dimensions of the
image when it is output to either the monitor or the printer. If the size of
the image to be output is different from the size of the original source
image, adjust the scaling percentage, or manually increase / decrease the
output values accordingly.
If you wish, you can also choose from a menu of predefined Output
settings. To do this, point your mouse to the words “Output” in the
Settings window, and choose the setting you wish from the drop-down
menu that appears.
Add / Remove Custom Setting: These options let you customize and create
