4.16.2 COMP (Comparator) MODE& DISP (Display) Mode
⚫ ABS
Set absolute values for the upper limit and lower limit values
of the measurement parameters.
The measurement values displayed are the same of the
measurement parameters.
⚫ △Abs
Enter reference values and then set absolute values corre-
sponding to the reference values as the upper limit and lower
limit values.
The measurement values displayed are displayed in devia-
tions (△Abs) from the reference value.
The following equation is used to calculate the comparison
UPPER/LOWER value
△Abs =    󰵎 
The following equation is used to display △Abs mode
△Abs =   
