1-4
ARC-6000
98-05012
R3
Product Volume: Use the INC/DEC switch to set the
full load value of the vehicle. (Pg. 2-14)**
% Rate: The percent by which the programmed
application rate can be changed with each activa-
tion of the INC/DEC switch when application is
underway. (Pg. 2-3)**
Application Rate: ERR, No function in SETUP
mode.
Total Applied: This is the flow meter calibration
number. (Pg. 2-8)**
Width: Individual boom section widths. The display
cycles through the individual boom sections in
order, unless a particular boom switch is activated
and the boom master switch is ON. (Pg. 2-3)**
Distance: Distance Calibration Number. (Pg. 2-4)**
Prime: Reads Pump L STnrd - Cannot be changed.
Test Speed: The current Test Speed (Pg. 2-12).**
S
tatus Switch
A
n external “ Implement Status” input can be
used to override the ARC control. The input
must present a positive voltage (+12.0 VDC)
on the green (or white) wire of the Boom Interface
Cable. As long as this condition is present, the
Control Console operates normally. If the voltage is
interrupted, the Control Console automatically stops
applying. At the same time, the Control Console will
either "HOLD" or "CLOSE" the Control Valve,
depending on the response selected by the operator.
(See Page 2-11).
This feature allows the operator to control the
operation of the control valve through the normal
operation of the vehicle. The Status input can be
used to sense the "ON"/"OFF" condition of the main
vehicle pump switch, a separate Master Switch, or, an
external switch monitoring an implement "UP"/
"DOWN" condition.
* Totals can be reset in this
mode.
** Values are programmable
in this mode.
*** Values changeable by a %
increase or decrease.
