2-12
ARC-6000
98-05012
R3
A. Set the Console to the following positions;
1. Power “ ON”
2. Mode Selector “ SETUP”
3. Display Selector “ TEST SPEED”
B. Use the INC/DEC switch to Set the Test Speed to the
desired value.
Rotating the Display Selector to the Test Speed position
causes the console to substitute the selected Test Speed
value for the Speed Sensor input.
Setting the Ground Speed Override (GSO) Value
T
o use the GSO feature, set the GSO value to the
minimum ground speed you want to control to
when the GSO Switch is activated. This should be
the lowest speed at which the sprayer can operate
smoothly and provide a good spray pattern. If you do not
intend to use this feature, set this value to zero (0.0).
Use the following procedure to set the GSO Speed.
A. Set the Console to the following positions;
1. Power “ ON”
2. Mode Selector “ SETUP”
3. Display Selector “ SPEED”
B. Use the INC/DEC switch to Set the GSO Speed to the
desired value.
CAUTION: When traveling at a speed slower than the
GSO speed setting, this feature will cause the Product
to be applied at a Rate consistent with the GSO speed,
rather than the true ground speed, possibly resulting
in serious over application. When Ground Speed
Override is being used, and the true ground speed is
less than the pre-selected “GSO” Speed, the console
will sound an alarm and the display will flash a “Too
Slow” message to warn the operator of possible over
application.
DISPLAY SELECTOR
Speed
Field Area Impl. Width
Distance
Test
Speed
Prime
Total Applied
Application Rate
OFF SET- UP DEC.
ON
OPERATE INC.
Scan
Product Vol.
Total Area
BOOMS
123456789
% Rate
B
A-1
A-2
A-3
Mid-T
ech
DISPLAY SELECTOR
Speed
Field Area Impl. Width
Distance
Test
Speed
Prime
Total Applied
Application Rate
OFF SET- UP DEC.
ON
OPERATE INC.
Scan
Product Vol.
Total Area
BOOMS
123456789
% Rate
B
A-1
A-2
A-3
