Appendix B SYSTEM O VERVIEW
How The ARC Controls Application Rate
T
he ARC System compares ground speed, active
boom width, and product flow rate four times a
second. A change in ground speed or boom
width results in a proportional change of material flow
rate to maintain a constant, pre-selected application
rate. High speed microprocessors and high resolution
sensors are used in the ARC System to allow it to
control the carrier application rate quickly and pre-
cisely.
ARC System Components
E
ach component is described below so the
operator has a general understanding of
function.
Fig. B-1 ARC
System Data Flow
