ARC-6000
HOW TO USE THIS MANUAL
T
his manual is designed to provide you with
the basic information needed to set up and
operate the MID-TECH
®
Automatic Rate Control (ARC)
spraying system. Actual procedures may vary somewhat,
depending on the configuration of your system.
When you see "Mitch", he is pointing out special information
that you should be aware of, regarding safety, preventing
console damage, an easier way to perform an operation, etc..
Below is a listing of the chapters in this manual, along with a
brief description of the information found in each chapter.
Chapter 1 - Switches and Controls - Lists each control switch,
on the face of the console, and gives a brief description of its
use.
Chapter 2 - Calibration and Setup - Takes you, step by step,
through the calibration of each sensor providing input to the
console, and the entering of other information the console
needs to perform the functions you require.
Chapter 3 - Operation - Briefly describes how to initiate the
spraying operation.
Chapter 4 - Trouble shooting - Lists possible causes and
remedies for the error codes that appear on the ARC display
if the console detects a problem.
Chapter 5 - Maintenance - Describes the basic maintenance
needed to keep your system operating at peak performance.
Chapter 6 - Emergency Operations - Suggests ways to operate,
under reduced accuracy, in the event of a major fault.
Appendix A - Sample system wiring and plumbing diagrams.
Appendix B - System Overview - Describes the major compo-
nents of the ARC system and their individual functions in
application control.
Appendix C - Glossary/Tables
Back Cover - Quick Start/Quick Set Up Guides
