Miele PG 8056 U - Technical Data

Technical data
119
Height 820mm (adjustable + 60mm)
Height with lid 835mm (adjustable + 60mm)
Width 598mm
Depth
Depth with door open
580mm
1,180mm
Weight (net) 70kg
Voltage, rated load, fuse rating See data plate
Connection cable Approx. 1.7m
Water temperature:
Cold water connection
Hot water connection
Max. 20°C
Max. 60°C
Static water connection pressure Max. 1,000kPa (10bar) overpressure
Recommended water connection pressure:
Cold and hot water connection 200kPa (2bar) overpressure
Minimum water connection pressure:
Cold and hot water connection 40kPa (0.4bar) overpressure
Delivery head Min. 0.3m, max. 1.0m
Drainage length Max. 4.0m
Ambient temperature 5°C to 40°C
Relative humidity
Maximum
Linear decreasing to
80% for temperatures up to 31°C
50% for temperatures up to 40°C
Inlet hoses Approx. 1.7m
Drain hose Approx. 1.5m
Safety class (according to DINEN60529) IP21
Noise emission values
Sound power in LwA
Sound pressure in LpA
Built-under dishwasher with wooden beam
in front of plinth on Short programme
59dB(A)
47dB(A)
Test certification VDE, EMC radio suppressed
CE mark 2006/42/EC Machinery Directive
UKCA mark (UK only) The Supply of Machinery (Safety)
Regulations 2008
Manufacturer address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
Importer United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road Abingdon, Oxon, OX14 1TW
Professional Sales, Tel: 0845 365 6608; E-mail: professional@miele.co.uk;
Internet: www.miele.co.uk/professional
