Technical Information
33
PW 6xx7
No. Program step Basic
setting
Setting options Notes
16 Wash time 1
No No No Wash time 1 carried out.
User-defined The programmer sets the drum agitation
for washing for a set duration with set
rhythm and speed. Time selectable
between 0 min 0 s and 99 min 59 s in 1-s
steps. Rhythm options “No”, “Normal”,
“Gentle+”, “Gentle” and “User-defined”.
With “User-defined”, the on time must be
between “2 s” to “99 s” and the off time
between “2 s” and “99 s” with the sum >
15 s. Speed options “No”, “Normal”,
“Drench” and “User-defined”. “User-
defined” selectable between 20 rpm and
70 rpm in 1-rpm steps.
17 Thermostop
No or lock
symbol (if No
has been
pro-grammed
under
Heating in
this table/
block)
Lock symbol Locked if no heating was selected.
No Heating begins when the minimum level is
reached. The program steps Wash time 1
and Wash time 2 are carried out without
the programmed or set temperature
having to be reached.
Yes Heating begins when the minimum level is
reached. The program step Wash time 1
is carried out. The program step Wash
time 2 starts only after the programmed or
set temperature has been reached
(Thermostop).
Disinfection Heating begins when the minimum level is
reached. The program step Wash time 1
is carried out. The program step Wash
time 2 starts only after the programmed or
set temperature has been reached
(Thermostop). In addition, if the
temperature drops below the lower level of
the programmed hysteresis (e.g., due to
peak-load cut-out, additional water intake
or power interruption, etc.), the control
returns to the Thermostop phase and the
program steps Wash time 2 and
Dispensing phase 2 start again from the
beginning.
18 Level 2
(dependent on
the setting for
Fill type in the
program header
for this program)
Auto load
control: 0
mm
0 to 350 mm Level 2 in mm wc (water column) can be
modified in 2 mm wc steps. The lower limit
is the minimum level for heating.
Water height
in mm: 0 mm
0 to 350 mm Level 2 in mm wc (water column) can be
modified in 2 mm wc steps. The lower limit
is the minimum level for heating.
Water
quantity in L:
0L
0 to permitted upper limit Level 2 in L in 1L steps: PW 6107 max. 95
L, PW 6137 max. 120 L, PW 6167 max.
125 L, PW 6207 max. 152 L.
Load-to-
liquor ratio in
kg/L: 1: 0.0
kg/L
1:0.0 kg/L, 1:0.5 kg/L,
1:1.0 kg/L, ..., to 1:20.0
kg/L
Level 2 as laundry:suds ratio in 0.5 kg/L
steps.
19 Intake path 2
Automatic Automatic Depending on the program block and the
current water temperature in the machine,
the control selects which valves to
operate. In order to save energy the
control will attempt to achieve the desired
wash cycle temperature during the first
water intake, if possible, by operating the
cold and hot water valves alternately. For
details, see tables at Section 100-4.2.
