Technical Information
34
PW 6xx7
No. Program step Basic
setting
Setting options Notes
19 Intake path 2
Automatic User-defined: Valve 1,
valve 2, valve 3, valve 4
The programmer selects No for water inlet
valves 1 to 4 or, for each valve, 1 of 11
possible options from the list K1, K2, K3,
K4, K6, KD, KH, WD, W1, W2. For details,
see tables at Section 100-4.2.
20 Dispensing
phase 2
No or lock
symbol, if
Dispensing
type has
been pro-
grammed to
No
Lock symbol Selection blocked because no dispensing
type has been programmed.
No No dispensing phase 2.
User-defined From a list of up to 13 dispenser pumps
(depending on model), up to 6 dispenser
pumps can be programmed for each
dispensing phase. The programmer can,
e.g., select the following with this
dispensing phase 2: “Dispensing:1”,
“Dispenser pump 7”, “Dispensed quantity:
100 mL”, “Dispenser time delay: 10 s”.
21 Dispensing stop
2
No or lock
symbol, if no
dispensing
type has
been pro-
grammed
Lock symbol Selection blocked because no dispensing
type has been programmed.
No Dispensing takes place at the same time
as program steps Intake path 2,
Agitation from level and Wash time 2. If
the duration of a dispensing cycle is longer
than Wash time 2, then it is stopped when
Wash time 2 finishes.
Yes The program step Wash time 2 starts
after dispensing has finished.
22 Level stop 2
No No Water inlet takes place at the same time
as program steps Dispensing phase 2,
Agitation from level and Wash time 2.
Yes Water is first taken in until the
programmed water level is reached. The
control interrupts further program
operation until this has occurred and then
starts drum agitation with the settings
made for program step Agitation from
level. The Wash time 2 step starts after
the programmed level 2 has been reached
or after the time set with program step
Agitation from level has elapsed.
23 Wash time 2
No No No Wash time 2 carried out (temperature
holding time).
User-defined The programmer sets the drum agitation
for washing for a set duration with set
rhythm and speed. Time selectable
between 0 min 0 s and 99 min 59 s in 1-s
steps. Rhythm options “No”, “Normal”,
“Gentle+”, “Gentle” and “User-defined”.
With “User-defined”, the on time must be
between “2 s" to “99 s" and the off time
between “2 s” and “99 s” with the sum >
15 s. Speed options “No”, “Normal”,
“Drench” and “User-defined”. “User-
defined” selectable between 20 rpm and
70 rpm in 1-rpm steps.
