OM-257 798 Page 12
3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
A
Amperage
Direct Current
(DC)
Alternating
Current (AC)
V
Voltage
Output Input Remote On
Off Positive Negative Voltage Input
Arc Force Constant Voltage
Variable
Inductance
Protective Earth
(Ground)
Increase Line Connection
Gas Metal Arc
Welding (GMAW)
Arc Force
U
0
Rated No Load
Voltage (OCV)
U
1
Primary Voltage
U
2
Conventional
Load Voltage
X
Duty Cycle
Hz
Hertz
IP
Degree Of
Protection
I
2
Rated Welding
Current
%
Percent
Cold Jog (Inch)
Away From
Workpiece
S
Suitable for Some
Hazardous
Locations
Three Phase Static
Frequency
Converter-Transfor
mer-Rectifier
Three Phase
I
1max
Rated Maximum
Supply Current
I
1eff
Maximum Effective
Supply Current
Wire Feed
Cold Jog (Inch)
Towards
Workpiece
Purge By Gas Constant Current Trigger Hold Off Read Instructions
Locked
I
1
Primary Current Sequence Program
Process Wire Type Gas Type Time
Arc Control
Trigger Hold On
Indicator Light
Trigger Hold
Off Indicator Light
