Millipore Milliflex Oasis - System Specifications Overview

Page 27 of 32
9. System specifications
Milliflex Oasis
®
pump
Frame Acrylonitrile Styrene Acrylate and
Polycarbonate, compatible with
standard UV sterilization
Filtration heads Two per pump, Stainless steel,
silicone, rubber gaskets
Note: The pump head including all
its components can be autoclaved at
121 °C for 15 minutes OR at 134 °C
for 5 minutes.
Pump dimensions
Height 90 mm (3.5 in.)
Width 230 mm (9.0 in.)
Depth 310 mm (12.2 in.)
Filtration
support height
70 mm (2.8 in.)
Weight with
ltration heads
3.4 kg (7.5 lb)
Power supply 100V–240V 50/60Hz — One set can be
used for up to three pumps
Milliflex Oasis
®
funnels
Filtration unit
Funnel, support
& lid material
Styrene butadiene copolymer (SBC)
Membrane ring
material
Polyethylene (PE)
Height 100 mL
funnel
57 mm (2.2 in.)
Height 250 mL
funnel
113 mm (5.5 in.)
Maximal
diameter
82 mm (3.2 in.)
2D code
identication
Datamatrix, can be read with standard
2D reader
Sterilization E-beam irradiation
Membrane
Material Mixed Cellulose Esters (MCE) or low
binding PVDF Durapore
Color White or black
Pore size 0.45 µm or 0.22 µm
Diameter 49 mm (1.9 in.) — same as Milliex
Milliflex Oasis
®
media plates
Material Polystyrene (PS)
R2A plate color Blue
TSA plate color Green
SDA plate color Pink
Maximal
diameter
66 mm (2.6 in.)
2D code
identication
Datamatrix, can be read with standard
2D reader
Milliflex Oasis
®
pump: materials in contact with
the liquid filtered
Part Material
Filtration head Stainless steel ASI 316 L
Silicone (gaskets & check valve)
Inner tubing Low-density polyethylene (LDPE)
Tubing ttings Polyphenylsulfone (PPSU)
Polypropylene (PP)
Acetal
Buna N rubber
Core pump module Polypropylene (PP)
FKM (Viton
®
)
PTFE (Teon
®
)
Drain tubing Silicone
