SCANNING PARAMETERS ( P720, P725 to P729 )
P720 SMART SCAN
Select the condition(s) to add / remove the Point Number displayed to the Priority Point scan
sequence ( as indicated by the display symbol in the RUN mode ).
In the RUN mode, if any of the conditions occur, Priority Point(s) are scanned each time a
non- priority point is scanned. Otherwise, all vessels are scanned in numerical sequence.
Selecting "manual" allows the addition or removal of priority points by the following methods:
» pressing on the local keypad
» sending an MT12 / MT13 message via the BIC-II ( see )
» sending the appropriate message via compatible industry bus
values: 0 = off ( numerical sequence only ) ( preset )
1 = manual
2 = Filling Indicator ( P702 ) value exceeded
3 = Emptying Indicator ( P703 ) value exceeded
4 = Filling / Emptying Indicator value exceeded
5 = Filling Indicator or Failsafe Timer ( P070 ) exceeded
6 = Emptying Indicator or Failsafe Timer ( P070 ) exceeded
7 = Filling / Emptying Indicator or Failsafe Timer exceeded
8 = Failsafe Timer exceeded
P725 AUXILIARY TRANSDUCER
Use this feature if a long range transducer measurement range, but a short range transducer
Nearest Distance ( see Transducer Mounting ) is required. In the RUN mode,
if the material level is within the short range transducer measurement range, that measurement
is processed. Otherwise, the long range transducer measurement is used.
With the long range transducer Point Number displayed, enter the short range Point Number.
values: 0 to 10 ( 0 = off, preset )
P726 LEVEL SYSTEM SYNC
Use this feature if another level measurement system is mounted near the XPL+.
See Interconnection / Level System Synchronization.
values: 0 = not required
1 = synchronize level monitors ( preset )
INSTALLATION
INSTALLATION
TECHNICAL REFERENCE
ENHANCED PARAMETERS
PL-532 63
