9
TECHNICAL DATA AND SPECIFICATIONS
81
Technical data Specification
Model MACS Elution Station
Size (w x d x h) 114 mm x 265 mm x 233 mm (4.5" x 10.4" x (9.2")
Weight 4.6 kg
Input voltage 24 V
Electric current 0.875 A
Power consumption 21 W
RS232-Interface (labeled "RS232/Display") Pin 1, 4, 6, 7, 8: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: 5 V
Pin 9: GND
CANwith high-power-contacts (labeled
"MultiMACS")
Pin 4, 5: NC
Pin A1: 24 V
Pin A2: GND
Pin 1: CAN_L
Pin 2: CAN_H
Pin 3: GND
Display-Interface (labeled "RS232/Display") Pin 1, 4, 6, 7, 8: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: GND
Pin 9: 5 V
USB-Interface (labeled "USB") Pin 1: 5 V
Pin 2: D-
Pin 3: D+
Pin 4: GND
Level-Detection (labeled "sensor Bottle") Inner Contact: LIQUID-DETECT-SIGNAL
Outer Contact: GND
Power supply (labeled "Power In") Pin 1,2,4: GND
Pin 3, 5: 24 V
DC-Output RS232 5 V / 0.4 A
Working temperature 15–30 °C
Humidity 0–85% relative humidity, non-condensing
Altitude max. 2,000 m
Emission sound pressure level at workstation <70 dB(A)
Table 9.2: Technical data of the MACS Elution Station.
