9.1 Technical data
Technical data Specification
Model MultiMACS Cell24 Separator
Size (w x d x h) 230 mm x 435 mm x 230 mm (9.1" x 17.1" x 9.1")
Weight 11 kg
Input voltage 100–240 V~, 50/60 Hz
Electric current 3.5 A max.
Power consumption 200 W
Fuses T3.15AH250V, 5×20 mm
RS232-Interface (labeled "com") Pin 1, 4, 6, 7, 8, 9: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: GND
RS232-Interface (labeled "display") Pin 1, 6, 7: NC
Pin 2: RXD
Pin 3: TXD
Pin 4: PGM_MODE
Pin 5: GND
Pin 8: RTS
Pin 9: 5 V
CANwith high-power-contacts (labeled
"module 1")
Pin 3, 4, 5: NC
Pin A1: 24 V
Pin A2: GND
Pin 1: CAN_L
Pin 2: CAN_H
Standard-CAN (labeled "module 2") Pin 1, 4, 5, 8: NC
Pin 2: CAN_L
Pin 3, 6: GND
Pin 7: CAN_H
Pin 9: 24 V
Supply voltage (labeled "power") Pin 1: mains voltage
Pin 2: mains voltage
Pin 3: protection conductor
DC-Output Module 1 24 VDC / 8 A
Module 2 24 VDC / 0.315 A
RS232 5 V / 0.75 A
Working temperature 15–30 °C
Humidity 0–85% relative humidity, non-condensing
Altitude max. 2,000 m
Emission sound pressure level at workstation <70 dB(A)
Table 9.1: Technical data of the MultiMACS Cell24Separator.
9
TECHNICAL DATA AND SPECIFICATIONS
80
