Minarik MM300 Series - Dimensions

3
Figure 1. MM301U and MM311U Dimensions
Dimensions
SIX (6) MOUNTING SLOTS
0.18 [5] WIDE x 0.30 [8] DEEP
ALL DIMENSIONS IN INCHES [MILLIMETERS]
4.46 [113]
3.00 [76]
0.70 [18]
0.19 [5]
0.60 [15]
1.90 [48]
0.77 [19]
0.98 [25]
6.30 [160]
6.90 [175]
