Minarik MM300 Series User Manual

1
Specifications
Max.
Armature HP Range HP Range
Current with 115 VAC with 230 VAC
Model (Amps DC) Applied Applied
MM311U 3.0
MM301U 10.0
AC Line Voltage 115 VAC or 230 V AC, 50 or 60 Hz, 1 Phase
Armature Voltage (115 VAC Input) 0–90 VDC
Armature Voltage (230 VAC Input) 0–180 VDC
Form Factor 1.37 at base speed
Field Voltage (115 VAC) 50 VDC (F1 to L1); 100 VDC (F1 to F2)
Field Voltage (230 VAC) 100 VDC (F1 to L1); 200 VDC (F1 to F2)
Maximum Field Current 1 ADC
Acceleration Time Range (with no load) 1-11 seconds
Deceleration Time Range (with no load) 1-11 seconds
Analog Input Voltage Range (S1 to S2) 0-10 VDC or 4-20 mADC
Input Impedance (S1 to S2) >100K ohms
Load Regulation (% of base speed)
with Armature Feedback 1% or better
with Tachogenerator Feedback 0.1%
Vibration 0.5G max. (0-50 Hz); 0.1G max. (>50 Hz)
MM301A 10.0
1/4–1 1/2–2
1/20–1/8 1/10–1/4
1/4–1 1/2–2
