Installation

Cage-clamp terminals

Logic connections are made to a cage-clamp terminals. To insert a wire into the cage-

clamp terminal:

1. Press down on the lever arm using a

small screwdriver.

2. Insert wire into the wire clamp

3. Release the lever arm to clamp wire.

Figure 5. Cage-Clamp Terminal
