14
Installation
Power Input
Connect the AC line power leads to terminals L1 and L2 and install a master power
switch in the voltage input line as shown in Figure 6 (page 13). The switch contacts
should be rated at a minimum of 250 volts and 200% of maximum drive current.
Field output
The field output is for shunt wound motors only. Do not make any connections to
F1 and F2 (TB501) when using a permanent magnet motor. See Table 2 for field
output connections.
Table 2. Field Output Connections for Chassis Drives
Line Voltage Approximate Connect Motor
(VAC) Field Voltage (VDC) Field To
115 50 F1 and L1
115 100 F1 and F2
230 100 F1 and L1
230 200 F1 and F2
