Application Notes

SPEED 2

SPEED 1

20K

OHM

20K

OHM

Figure 17. Independent Adjustable Speeds

Independent adjustable speeds

Replace the speed adjust potentiometer with a single pole, multi-position switch, and

two or more potentiometers in parallel, with a total parallel resistance of 10K ohms.

Figure 17 shows the connection of two independent speed adjust potentiometers that

can be mounted at two separate operating stations.
