23
Installation
Figure 9. MM301A AC Line, Motor and Field Connections
1. L1 IS THE HOT TERMINAL.
2. L2/115 IS THE NEUTRAL TERMINAL FOR 115 VAC INPUT.
3. L2/230 IS THE NEUTRAL TERMINAL FOR 230 VAC INPUT.
4. TYPICAL FIELD CONNECTIONS SHOWN. REFER TO TABLE 2 (PAGE 14)
5. REMOVE THE 510 OHM INTERNAL RESISTOR CONNECTED BETWEEN
TERMINALS 8 & 9 IF YOU ARE USING A 0-10V REMOTE INPUT SIGNAL
230 VAC
115 VAC
115/230 VAC
LINE VOLTAGE INPUT
MOTOR
ARMATURE
+
–
FIELD
COIL
SEE NOTES 1,
2, AND 3
SEE NOTE 4
COM (
–) REF (+)
0 – 10 VDC OR
4 – 20 mADC
INPUT SIGNAL
EARTH GROUND
(GREEN SCREW)
1L
2L )032(
2
L
)511(
1F
2
F
1A
2A
MOC
FER
1 2 3 4 5 6 7 8 9
