Mindeo MS3690 - 1-1 Technical specifications

1
1 Specifications
1-1 Technical specifications
Table 1-1 Technical specifications
MS3690-1D
MS3690-2D
Working range
Bluetooth: 30m(line of sight)
Wi-Fi: 100m(line of sight)
Radio link
Bluetooth: 2.4–2.5GHz, Bluetooth 4.0/3.0/2.1+EDR, Class 2
Wi-Fi：2.4GHz, compliant with Wi-Fi IEEE 802.11 b/g/n protocol standards
Interface
Bluetooth: HID keyboard, SPP, BLE
Wi-Fi: Station mode(STA), Access Point mode(AP)
USB: USB HID keyboard, USB virtual COM, U Disk
Data storage
4MB for out of range batch: 250,000 barcodes(each barcode is of 15 bytes)
8MB for data batch mode: 500,000 barcodes(each barcode is of 15 bytes)
76MB for U Disk mode: 5,000,000 barcodes(each barcode is of 15 bytes)
Keyboard layout
USA
、
Turkish F/Q
、
French
、
Italian
、
Spanish
、
Slovak
、
Denmark
、
Japanese、
German
Dimensions
Length × Width × Depth: 12.5×4.6×3.1cm
Weight 115g
Color Gray/Black/White/Customization
Case material ABS
Indicator Beeper、LED、Vibrator
Display
OLED display(128×64)with LED backlight
Operating mode Handheld
Programming
method
Manual(reading special barcode),On-Screen(pressing special keys)
Firmware upgrade Online via USB interface
Input Voltage
4.75V – 5.25V
Standby current
Bluetooth: 4 mA
Wi-Fi: 4 mA
Bluetooth: 7 mA
Wi-Fi: 7 mA
Working current
Bluetooth: 75 mA (Bluetooth
On)
Wi-Fi: 127 mA (Wi-Fi On)
Bluetooth: 80 mA (Bluetooth On)
Wi-Fi: 132 mA (Wi-Fi On)
Scanning current
Bluetooth: 135 mA (Bluetooth
On)
Wi-Fi: 187 mA (Wi-Fi On)
Bluetooth: 450 mA (Bluetooth On)
Wi-Fi: 506 mA (Wi-Fi On)
Battery 1900 mAh Lithium-ion battery
Charging time Fully charged(>80%)in 4 hours
Charge current 500mA
