to be deleted should be deselected and then deleted.
5-2-5-3 Format
Note 1: The format function is a quick way to empty a whole U Disk.
Note 2: Please format the U Disk once before the first time of use.
Caution:
1. Format operation will erase all data on the disk.
2. Format operation is not undoable. It is strongly recommended to back up the data before format
operation.
5-2-6 Data batch
The terminal starts storing barcode data in Date Batch mode. The collected barcode data can then be
sent to a host via Bluetooth/USB. Three options are listed below.
Send batch data - Data transmission is triggered by this menu command. Before undertaking this
operation, make sure a communication link (Bluetooth network or USB cable) is working.
Interfaces - There are three types of communication interfaces Bluetooth, USB HID keyboard and USB
virtual COM. A Bluetooth link is needed in the first case (See 5-3 System Setting - Bluetooth).
Auto Clear – By enable, the terminal will clear the stored barcode after finishing sending, if Auto Clear is
enabled.
Inter Barcode Delay – set the delay time for transmission of data
5-3 System Setting
5-3-1 Bluetooth Functionalities
The terminal can be configured to send data to a PC/Notebook/PDA/other instrument which has an
integrated Bluetooth module or is connected with an external Bluetooth USB adapter. A diagram of
Bluetooth functionalities and a table of various Bluetooth profiles are shown below, respectively:
Table 5-1 Various Bluetooth profiles
HID Keyboard
The terminal connects to the PC/host via Bluetooth and behaves like a keyboard.
The terminal accepts incoming connection requested from a remote device and is
the slave.
SPP
The terminal connects to the PC/host via Bluetooth and behaves like there is a
serial connection.
BLE slave
A Bluetooth 4.0 device will pair with the terminal, so that the terminal can transfer
data with low power.
Cradle
The terminal connects to the PC via cradle and behaves like a keyboard.
BLE master
Only use in MS3 SDK
Note: Bluetooth-enabled smart phones and PDAs can host the terminal in general. However, ordinary
mobile phones with Bluetooth function can not be a host of the terminal because in most cases neither
HID nor SPP profile is supported by them.
5-3-1-1 Configure Blueto-oth HID Keyboard profile communication
Note : make sure the Bluetooth module of the terminal is powered on (blue LED is on) and the selected
profile is HID Keyboard.
Step 1: Plug a Bluetooth USB adapter into the USB port of the computer.
Step 2: Double-click the Bluetooth icon at the right bottom corner on Windows 7 (
).
Step 3: Click Add to search devices nearby.
Step 4: Select the terminal you want to connect and then click Next.
Step 5: You can change the name through the terminal(System Information-> Bluetooth Info)
Step 6: The terminal use the simple pair mode. If a pair code popping, you can directly select YES and
click Next, and then you can finish the connection.
