BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual 6-25
6.7 Disassembling the Module Rack
1. Removing the handle and hooks
 As shown in the following figure, loosen and remove the eight M3X10 cross recessed screws, and
remove the hooks.
 As shown in the following figure, loosen and remove the three M3×8 cross recessed screws, and
remove the handle.
M3X10
M3X8 screw
