3. Connector Panel
FIGURE 1-5 Connector Panel
a. NIBP Pneumatic Fitting
• This Rectus*, Quick-Connect pneumatic fitting is used to attach the NIBP hose to
the Duo.
b. SpO
2
Receptacle (optional)
• This receptacle is used to attach the SpO
2
sensor to the Duo. The two versions of
SpO
2
technology that are available for use with the DUO are Masimo
®
and
Nellcor
®
.
* Quick Connect Pneumatic Fittings available from Rectus-TEMA Corporation.
