Mindray DP-50 User Manual

DICOM 10-1
10 DICOM
NOTE:
Before using DICOM, please read the electronic file DICOM CONFORMANCE
STATEMENT along with the device.
This chapter is confined to the preset, connection verification and DICOM services of the
DICOM-configured ultrasound machine, not including SCP configurations like PACS/ RIS/ HIS.
The DICOM package is optional, so the description here is only applicable for the system
configured with the DICOM package.
This system supports the following DICOM functions:
 DICOM Basic functions: DICOM verify connectivity, DICOM task management,
DICOM storage, DICOM print, DICOM storage commitment, DICOM media storage
(DICOMDIR review)
 DICOM Worklist
 DICOM MPPS
 DICOM Query/Retrieve
 DICOM OB/GYN Structured Report
 DICOM Vascular Structured Report
 DICOM Cardiac Structured Report
Workflows of DICOM preset and application are briefly described as follows:
1. DICOM preset (network preset, DICOM preset and DICOM service)
2. Verify connection.
3. DICOM Services (image storage, print, Worklist, storage commitment, media storage,
DICOMDIR review, task management).
Abbr. used in this chapter:
Abbr.
Descriptions
DICOM
Digital Imaging and Communications in
Medicine
AE
Application Entity
PDU Protocol Data Unit
SCU
Service Class User (DICOM client)
SCP Service Class Provider (DICOM server)
SOP
Service-Object Pair
10.1 DICOM Preset
10.1.1 Network Preset
NOTE
DO Not edit IP address in Network Preset page as the network task is executed,
otherwise it fails. View if there is any undergoing task in task manager of the system.
Preset local TCP/IP settings.

Mindray DP-50 Specifications

General

Transducer Ports	2
Cine Loop	Yes
Type	Portable Ultrasound System
Probes	Convex, Linear
Connectivity	USB, DICOM
Power Supply	100-240V~ 50/60Hz
Applications	Obstetrics, Gynecology, Urology, Cardiology
