9
T1 Quick Reference Guide
DPM Central Station will initiate a NIBP measurement on the T1 bedside
monitor.
Set a Non-Invasive Blood Pressure Measurement Interval
The T1 allows the clinician to set an interval for a NIBP measurement to be
obtained automatically. To set an automatic interval on the T1 monitor:
a. Select NIBP numeric tile to enter the NIBP Setup
b. Select Interval and adjust value using up and down arrows
c. Select Main Menu
(quick key) or to return to the main display
To stop the current NIBP measurement for a patient on the T1 monitor, select
NIBP
(quick key) on the main display.
DPM Central Station Interface: Selecting Stop NIBP Measurement on the
DPM Central Station will stop a NIBP measurement on the T1 bedside monitor.
To stop all NIBP measurements for a patient on the T1 monitor:
a. Select NIBP numeric tile or select NIBP Setup >> from Parameters >> in
Main Menu
(quick key) to enter the NIBP Setup menu
b. Select Stop All
c. Select Main Menu
(quick key) or to return to the main display
INVASIVE BLOOD PRESSURES
The T1 monitor allows a clinician to monitor up to 2 invasive blood pressures
(IBP) simultaneously with the included Y-type IBP adapter cable. The T1
monitor allows the clinician to monitor one IBP with a direct IBP cable
connection.
Adjust Invasive Blood Pressure Label
To adjust the label on an invasive blood pressure on the T1 monitor:
a. Select displayed invasive blood pressure waveform or IBP numeric tile to
enter the invasive blood pressure Setup menu
Or
a. Select the invasive blood pressure setup (i.e. ART Setup >>) from
Parameters >> in Main Menu
quick key) to enter the invasive
blood pressure Setup menu
b. Select IBP Label and adjust the label using the up and down arrow keys
To Next Page
