T1 Quick Reference Guide
a. Select ECG waveform or ECG numeric tile to enter the ECG Setup menu
Or
a. Select ECG Setup >> from Parameters >> in Main Menu
(quick key)
to enter the ECG Setup menu
b. Select Others >>
c. Select Lead Set to select a lead set from the drop down list
d. Select ECG to adjust lead (3 lead) or select ECG1 to adjust the first lead
and ECG2 to adjust the second lead (5 lead)
e. Scroll and select lead from the drop down menu
f. Select Main Menu
(quick key) or to return to the main display
DPM Central Station Interface: Adjusting ECG leads on the T1 bedside
monitor and DPM Central Station are independent.
Panorama Central Station Interface: Adjusting ECG leads on the T1 bedside
monitor, Panorama Central Station, WorkStation, and ViewStation are
independent.
Enable Pacemaker Detection and Set Pacemaker Rate
The T1 allows the clinician to enable pacemaker detection. The symbol is
displayed when the pacemaker detection is enabled.
To enable the pacemaker detection on the T1 monitor:
a. Select ECG waveform or ECG numeric tile to enter the ECG Setup menu
Or
a. Select ECG Setup >> from Parameters >> in Main Menu
(quick key)
to enter the ECG Setup menu
b. Scroll and select Others >>
c. Select Paced to Yes
d. Scroll and select Pacemaker Rate
e. Adjust Pacemaker Rate using the up and down arrows
f. Select Main Menu
(quick key) or to return to the main display
DPM Central Station Interface: Pacemaker enhancement on the T1 bedside
monitor and DPM Central Station are independent.
