17
T1 Quick Reference Guide
e. Select Main Menu (quick key) or to return to the main display
Or
a. Select SpO
2
waveform or SpO
2
numeric tile to enter the SpO
2
Setup menu
b. Select Beat Vol
c. Select volume ranging from 0-10 (0=Off 10=Max)
d. Select Main Menu
(quick key) or to return to the main display
Note: The QRS tone is derived from either the HR or PR, depending on which
is currently selected as the alarm source. When monitoring SpO
2
, there is a
variable pitch tone which changes as the patient’s saturation level changes.
The pitch of the tone rises as the saturation level increases and falls as the
saturation level decreases.
ALTERNATE OPERATING MODES
The T1 has the alternate operating modes to reduce disturbing patient.
Night Mode
To reduce brightness, volumes, and NIBP measurement acquisition on the T1
bedside monitor:
a. Scroll and select Screen Setup >> from Main Menu
(quick key)
b. Select Night Mode >>
c. Scroll and select Enter Night Mode
To remove a patient from Night Mode:
a. Scroll and select Screen Setup >> from Main Menu
(quick key)
b. Select Night Mode >>
c. Select Ok
DPM Central Station Interface: Night Mode can be enabled/disabled on the
DPM Central Station.
Panorama Central Station Interface: Night Mode is not supported at the T1
bedside monitor when interfacing to the Panorama Central Station.
Privacy Mode
To suspend alarm notification and turn off the display on the T1 bedside
monitor when admitted to the DPM Central Station:
